Alignment method 6 motors core to core alignment
Applicable fiber SM (G.652)，MM(G.651)，DS(G.653)，NZDS(G.655)
Cladding diameter 80 -150μm
Coating diameter 160–1000μm
Cleaved length 5-16mm (coating diameter ＜ 250um), 16mm (coating diameter:250-1000um)
Typical splice loss SM: 0.02dB；MM: 0.01dB；DS: 0.04dB；NZDS: 0.04dB
Return loss ＞60dB
Splicing program 40 groups
Operation mode Manual/ Automatic
Auto- heating Available
Typical splice time 6 seconds
Typical heating time 18 seconds for 60mm and 40mm shrinkable sleeves
Fiber magnification 250X (X or Y view), 125X (X and Y view)
Viewing display Dual high sensitivity camera, 5 inches 800*480 LCD Monitor
Data storage 4000 groups data records
Loss evaluation Available
Tension test 1.8～2.25N
Interface GUI menu interface, easy for operation
Battery capacity 5200mAh Li-battery, 300 cycles splicing and heating
Power supply Adaptor, input: AC100-240V(50/60HZ), output: DC11-13.5V
Electrode life More than 4000 ARC discharges, easy to replace
Terminals USB 2.0 port, for software upgrading, records exporting
Operating Altitude: 0-5000m, Humidity:0-95%, Temp: -10 ℃ ～ +50 ℃ ; Wind: Max 15m/s
Dimension/Weight 156mm (L)×141mm (W)×156mm (H) /2.45kg (including battery)
