Brands
MikroTik
Wi-Fi
Wi-Fi 6 (802.11ax); Dual-Band (2.4 & 5 GHz) with MU-MIMO Support (4 x 4)
Throughput
3600 Mb/s Total
5 GHz: 2400 Mb/s
2.4 GHz: 1148 Mb/s
Inputs/Outputs
8x RJ45 Gigabit Ethernet
8x RJ45 Gigabit Ethernet PoE+ (30 W, 802.3at)
2x SFP+
1x RJ45 RS-232 (Console)
1x USB-A 3.0 / 3.1/3.2 Gen 1
Wireless
Wi-Fi
Wi-Fi 6 (802.11ax); Dual-Band (2.4 & 5 GHz) with MU-MIMO Support (4 x 4)
Number of Antennas
4x External
Antenna Gain
6 dBi
Supported Protocols
Auto-MDIX/MDI
Antenna Placement
External (Unspecified Connection Type)
Bluetooth
No
Cellular Support
No
Performance
Throughput
3600 Mb/s Total
5 GHz: 2400 Mb/s
2.4 GHz: 1148 Mb/s
Interface
Inputs/Outputs
8x RJ45 Gigabit Ethernet
8x RJ45 Gigabit Ethernet PoE+ (30 W, 802.3at)
2x SFP+
1x RJ45 RS-232 (Console)
1x USB-A 3.0 / 3.1/3.2 Gen 1
USB Sharing Support
Yes
Security
Guest Network Support
No
Wireless Security
AES, WPA3
VPN Protocol
No
Firewall Support
No
Lock Slot
No
Management
Mobile App Compatible
No
Hardware
RAM
1 GB
Storage Capacity
128 MB
CPU
Quad-Core: Up to 2.2 GHz
Supported IEEE Standards
802.11a, 802.11ac, 802.11ax, 802.11b, 802.11g, 802.11n
DOCSIS Support
Yes
Electrical
Input Power
100 to 240 VAC, 50 / 60 Hz
Power Consumption
≤227 W
General
Environmental Resistance
No
Certifications
CE, EAC, RoHS
Operating Conditions
-4 to 158°F / -20 to 70°C
Dimensions
17.4 x 9.8 x 1.7″ / 443 x 250 x 44 mm
Packaging Info
Package Weight
8.185 lb
Box Dimensions (LxWxH)
23.2 x 15.6 x 4.8″
