MikroTik
Product Code C53UiG+5HPaxD2HPaxD
CPU Quad-Core IPQ-6010 1.8 GHz
CPU architecture ARM 64bit
Size of RAM 1GB
Storage 128 MB, NAND
Number of 1G Ethernet ports 4
Number of 2.5G Ethernet ports 1
USB 1 USB 3 type A
Switch chip model IPQ-6010
Wireless interface model QCN-5022 (2.4 GHz), QCN-5052 (5 GHz)
Wireless 2.4 GHz 802.11b/g/n/ax dual-chain
5 GHz 802.11a/n/ac/ax dual-chain
Wireless antenna max gain 2.4 GHz (3.3 dBi), 5 GHz (5.5 dBi)
Dimensions 251 x 130 x 39 mm
Operating system RouterOS v7
Operating temperature -40°C to +70°C
Power
Number of DC inputs 2 (PoE-in, DC jack)
PoE-in input Voltage 18-28 V
DC jack input 12-28 V
PoE-out Passive PoE Ether1, max out per port output (input < 30 V): 0.625 A PoE-out total output 15 W Power adapter nominal voltage 24 V Power adapter nominal current 1.5 A Max power consumption (without attachments) 15 W Max power consumption 38 W Wireless Rate (2.4 GHz) Tx (dBm) Rx (dBm) 1MBit/s 27 -100 11MBit/s 27 -94 6MBit/s 29 -96 54MBit/s 27 -80 MCS0 29 -96 MCS7 26 -75 MCS9 24 -70 MCS11 22 -67 Rate (5 GHz) Tx (dBm) Rx (dBm) 6MBit/s 28 -96 54MBit/s 26 -80 MCS0 28 -96 MCS7 25 -75 MCS9 23 -70 MCS11 20 -67
