Interfaces
Ports 8 x 10/100/1000 Mb/s Gigabit Ethernet (RJ45) PoE
Protocols
Supported Protocols Auto-MDIX/MDI
MAC Filtering
Queuing Weighted Round Robin (WRR)
Jumbo Frames Support 9216 Bytes
MAC Address Table Size 4K
Standards
Supported IEEE Standards 802.1p, 802.3, 802.3ab, 802.3af, 802.3az, 802.3i, 802.3u, 802.3x
Performance
Latency 3 µs
Forwarding Rate 1.44 Mpps
Switching Bandwidth 16 Gb/s (Non-Blocking)
Packet Buffer 192 kB
Electrical
Power Draw 87.9 W (Active)
1.23 W (Standby)
PoE Power Budget 83 W
PoE per Port 30 W
Environmental
Operating Temperature 32 to 104°F / 0 to 40°C
Operating Humidity 90%
Storage Temperature -4 to 158°F / -20 to 70°C
Storage Humidity 95%
Operating Altitude 10,000′ / 3048 m
General
Cooling System Passive
Mean Time Between Failures (MTBF) 2,752,476 Hours
Material of Construction Metal
Indicator Lights Link/Activity/Speed, PoE, Power
Dimensions 9.3 x 4 x 1.1″ / 236 x 102 x 27 mm
Weight 1.3 lb / 0.6 kg
