HARDWARE FEATURES
Interface 1× 2.5G Ethernet Port
Button Reset
Power Supply 802.3at PoE or 12V/1.5A DC (Power Adapter Is Not Included)
Power Consumption • 19.5 W (For PoE);
• 16.8 W (For DC)
Dimensions ( W x D x H ) 6.3 × 6.3 × 1.4 in (160 × 160 × 36.7 mm)
Antenna Type • 2.4 GHz: 2× 4.0 dBi
• 5 GHz: 2× 5.0 dBi
Mounting Ceiling / Wall Mounting (Kits Included)
WIRELESS FEATURES
Coverage 140㎡(1500 ft²)***
Wireless Client Capacity 250+**
Wireless Standards IEEE 802.11 a/b/g/n/ac/ax/be
Frequency 2.4 GHz and 5 GHz
Signal Rate 688 Mbps (2.4 GHz) + 4324 Mbps (5 GHz)
Wireless Functions • 4K-QAM‡
• Seamless Roaming
• MU-MIMO‡
• EHT240‡
• Mesh△
• OFDMA‡
• Load Balance
• Band Steering
• Beamforming
• Airtime Fairness
• Multiple SSIDS:16(8 on each band)
• Wireless Schedule
• Reboot Schedule
• QoS(WMM)
• Rate Limit
• Static IP/Dynamic IP
• RADIUS Accounting
• MAC Authentication
Wireless Security • Captive Portal Authentication△
• Access Control
• Maximum number of MAC Filter: 4,000
• Wireless Isolation Between Clients
• VLAN
• Rogue AP Detection
• WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise
Transmission Power < 25 dBm (2.4GHz) < 25 dBm (5GHz, band 1&band 4) < 24 dBm (5GHz, band 2&band 3) MANAGEMENT Omada App Yes Centralized Management • Omada Cloud-Based Controller • Omada Hardware Controller • Omada Software Controller Cloud Access Yes. Require the use of an OC300, OC200, Omada Software Controller, or an Omada Cloud-Based Controller. Email Alerts Yes LED ON/OFF Control Yes Management MAC Access Control Yes SNMP v1, v2c, v3 System Logging Local/Remote Syslog Yes Web-based Management Yes OTHERS Certification CE, FCC, RoHS, IC Package Contents • EAP723 • Installation Guide • Ceiling/Wall Mounting Kit Environment • Operating Temperature: 0 °C–40 °C (32 °F–104 °F); • Storage Temperature: -40 °C–70 °C (-40 °F–158 °F); • Operating Humidity: 10%–90% non-condensing; • Storage Humidity: 5%–90% non-condensing;
