Weight 40000 g
HARDWARE FEATURES
Service Port 8*PON port (SFP Slot)
Management Port 1*RJ45 Console port
1*USB Type-C console port
1*100/1000BASE-TX out-band management port
Redundancy Design Dual power supply Support
AC, DC, AC+DC power input
Fan Quantity 4
Power Supply AC: 90V~240V, 50/60Hz
DC: -36V~-72V
Power Consumption Max. 70W
TX Power Class B+: 1.5dBm~5dBm
Class C+: 3dBm~7dBm
Weight 4kg
Data Rates Downstream: 2.5Gbps
Upstream: 1.25Gbps
Dimensions ( W x D x H ) 440mm(L)*391mm(W)*44mm(H)
Transmission Distance 20km
Wavelength Tx: 1490nm
Rx: 1310nm
SOFTWARE FEATURES
PON Features Compatible with ITU-T G.984.x, G.988 standards
Standard OMCI management function
Support 1:128 splitting ratio for each PON port
Support AES 128 encryption for uplink and downlink data transmission.
DBA algorithm, support 5 DBA types ONU management (remote configuration, upgrade, monitor)
ONU authentication
Multicast IGMP v1/v2 snooping
IGMP fast leave
IGMP snooping querier
Multicast VLAN
Quality of Service Support 802.1p QoS
4 priority queues
Priority schedule mode: SP, WRR
Support basic ACL, advance ACL and link ACL
Basic ACL: source IP
Advance ACL: source IP, destination IP, source port, destination port, DSCP and IP message type
Link ACL: source MAC, destination MAC, VLAN ID, Ethernet type
Support 802.1p priority, VLAN ID, TOS, DSCP remark.
VLAN VLAN ID: 1~4094
Support 802.1q VLAN
The ports support Access, Trunk and Hybrid mode
Support PVID configuration
Support QinQ
Support VLAN translation
Management Support CLI management
Support dual image
Support EMS management based on SNMP
Console port, Management port
Inbound and outbound management
Operation Status monitor
2 levels account management
Configuration backup and load
Firmware upgrade through FTP
Log management
Real-time statistic
OLT and ONT optical module diagnostics
DHCP DHCP Client, DHCP Snooping
Spanning Tree RSTP
OTHERS
Environment Operating temperature: 0℃~50℃
Storage temperature: -40℃~85℃
Operating Humidity: 5%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
